Wall Mounted Freezer 2 Door

Top Cabinet

Model: AHE1450TCF

Dimensions and Capacity

Product Dimensions (W × D × H): 1450 × 590 × 1022 mm

Internal Dimensions (W × D × H): 1330 × 390 × 645 mm

Gross Volume: 373 L

Net Volume: 232 L

Shelves: 4 white metal shelves with 16 mm wire spacing

Operating Environment

Climatic Class: 3

Maximum Altitude: ≤1500 m

Rated Voltage / Frequency: 220 V / 50 Hz

Power Plug / Cord Length: UK plug / 2 m

Door and Cabinet

Canopy: Flat metal canopy with light cover, painted black

Door Frame: Extruded aluminium frame with plastic core, finished in black

Number of Doors / Opening Style: 2 rotating doors

Door Glass: 25 mm triple-layer glass, 4 + 3 + 4 mm, D-tempered with electric anti-condensation heater

Door Opening Direction: Side to side, starting from the left

Self-Closing Doors: Yes

Door Lock: Standard round lock located on the grille

Door Handle: Integrated extruded aluminium handle, finished in black

Front Grille: Flat painted metal grille, finished in black

Cabinet Exterior: Black pre-coated steel

Display and Lighting

Display Area: 0.74 m²

Price Bar: 38 mm high, black, without cover

Refrigeration System

Refrigerant / Charge: R290 / 80 g

Temperature Range: −22 to −18°C

Cooling System: Frost-free

Cooling Switch: Yes

Mechanical Thermometer: No

Defrost Water Disposal: Self-evaporation

Compressor: Standard fixed-speed compressor

Noise Level: 62 dB

Electrical and Energy Details

Temperature Control: Electronic thermostat

Controller Position: On the canopy

Energy Standards: EU 2019/2018 and EU 2019/2024

Energy Class: E

Daily Energy Consumption: 14.43 kWh per 24 hours

Input Power: 650 W

Rated Current: 4.7 A

Defrost Type: Hot gas

Defrost Power: 741 W

Packaging and Logistics

Package Dimensions (W × D × H): 1540 × 660 × 1155 mm

Net Weight: 139 kg

Gross Weight: 149 kg

Number of Feet: 4

Bottom Cabinet

Model Information

Model: ZCD-L145S-S4T

Operating Environment

Climatic Class: 3

Rated Voltage / Frequency: 220 V / 50 Hz

Power Plug / Cord Length: UK plug / 2 m

Front Glass and Handle

Front Glass: Single-layer 4 mm S-tempered glass with Low-E coating

Front Sliding Bar: Black extruded POM

Sealing Strip: Brown wool sealing strip

Insulation: Black EPDM sponge

Handle: Black injection-moulded ABS

Dimensions and Capacity

Product Dimensions (W × D × H): 1454 × 850 × 1080 mm

Internal Dimensions (W × D × H): 1303 × 691 × 733 mm

Gross Volume: 575 L

Net Volume: 402 L

Display and Lighting

Display Area: 0.75 m²

Internal Lighting: P-type LED, 10 W + 14 W, 9000–10000 K

Price Bar: Black PC sticker

Refrigeration System

Refrigerant / Charge: R290 / 105 g

Temperature Range: −22 to −15°C

Cooling System: Direct cooling

Cooling Switch: Yes, integrated into the controller

Defrost Water Disposal: Self-evaporation

Compressor: Standard fixed-speed compressor

Noise Level: 60 dB

Electrical and Energy Details

Temperature Control: Electronic thermostat

Controller Position: Bottom-right corner

Energy Standards: EU 2019/2018 and EU 2019/2024

Energy Class: E

Daily Energy Consumption: 8.22 kWh per 24 hours

Input Power: 420 W

Rated Current: 3 A

Defrost Power: 727 W

Packaging and Logistics

Package Dimensions (W × D × H): 1554 × 994 × 1010 mm

Net Weight: 101 kg

Gross Weight: 138.5 kg

Castors: Castors with and without locks
